Diodes Inc MMBT3904LP-7B NPN Transistor, 200 mA, 40 V, 3-Pin DFN-1006 [MMBT3904LP-7B]; 165-8487
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Transistor Type | NPN |
| Maximum DC Collector Current | 200 mA |
| Maximum Collector Emitter Voltage | 40 V |
| Package Type | DFN-1006 |
| Mounting Type | Surface Mount |
| Maximum Power Dissipation | 1 W |
| Minimum DC Current Gain | 30 |
| Transistor Configuration | Single |
| Maximum Collector Base Voltage | 60 V |
| Maximum Emitter Base Voltage | 6 V |
| Maximum Operating Frequency | 100 MHz |
| Pin Count | 3 |
| Number of Elements per Chip | 1 |
| Width | 0.675mm |
| Minimum Operating Temperature | -55 °C |
| Dimensions | 1.07 x 0.67 x 0.48mm |
| Maximum Base Emitter Saturation Voltage | 0.65 V |
| Maximum Collector Emitter Saturation Voltage | 0.2 V |
| Length | 1.07mm |
| Maximum Operating Temperature | +150 °C |
| Height | 0.48mm |
