Diodes Inc ZTX696B NPN Transistor, 500 mA, 180 V, 3-Pin TO-92 [ZTX696B]; 885-5665
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Transistor Type | NPN |
| Maximum DC Collector Current | 500 mA |
| Maximum Collector Emitter Voltage | 180 V |
| Package Type | TO-92 |
| Mounting Type | Through Hole |
| Maximum Power Dissipation | 1 W |
| Minimum DC Current Gain | 500 |
| Transistor Configuration | Single |
| Maximum Collector Base Voltage | 300 V |
| Maximum Emitter Base Voltage | 5 V |
| Maximum Operating Frequency | 50 MHz |
| Pin Count | 3 |
| Number of Elements per Chip | 1 |
| Maximum Collector Emitter Saturation Voltage | 0.3 V |
| Width | 2.41mm |
| Maximum Operating Temperature | +200 °C |
| Height | 4.01mm |
| Transistor Material | Si |
| Dimensions | 4.77 x 2.41 x 4.01mm |
| Length | 4.77mm |
| Minimum Operating Temperature | -55 °C |
| Maximum Base Emitter Saturation Voltage | 1 V |
