EPCOS 680nF Polypropylene Capacitor PP 750 V dc, 900 V dc ±10% Tolerance B32674 Series [B32674D1684K000]; 882-9329
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 680 nF |
| Voltage | 750 V dc, 900 V dc |
| Tolerance | ±10% |
| Series | B32674 |
| Lead Pitch | 27.5mm |
| Length | 31.5mm |
| Depth | 11mm |
| Height | 19mm |
| Dimensions | 31.5 x 11 x 19mm |
| Dielectric | MKP |
| Terminal Type | Radial |
| Minimum Operating Temperature | -40°C |
| Lead Diameter | 0.8mm |
| Maximum Operating Temperature | +105°C |
| Dissipation Factor | ≤0.005 % @ 1kHz |
| Dielectric Material Family | Metallised Polypropylene Film |
| Equivalent Series Resistance | 34.7mΩ |
| Lead Length | 6mm |
