EPCOS 5600μF 350V dc Aluminium Electrolytic Capacitor, Chassis Mount 76.9 x 130.7mm +105°C 76.9mm 31.7mm [B43740A4568M000]; 171-1181
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 5600 µF |
| Voltage | 350 V dc |
| Mounting Type | Screw Mount |
| Technology | Electrolytic |
| Dimensions | 76.9 x 130.7mm |
| Height | 130.7mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 76.9mm |
| Maximum Operating Temperature | +105°C |
| Lifetime | 6000h |
| Lead Pitch | 31.7mm |
| Series | B43740 |
| Tolerance | ±20% |
| Leakage Current | ≤0.018 μA (Cr/μF x Vr/V)^0.85 + 4 μA |
| Equivalent Series Resistance | 20mΩ |
| Ripple Current | 41A |
