EPCOS B84142-A Series 30A 250 V ac 60Hz Flange Mount RFI Filter, with Screw Terminals, Single Phase [B84142A0030R000]; 414-0635
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Maximum Current Rating | 30A |
| Maximum Voltage Rating | 250 V ac |
| Mounting Type | Flange Mount |
| Termination Style | Screw |
| Number of Phases | 1 |
| Number of Stages | Two Stage |
| Series | B84142-A |
| Operating Frequency | 60Hz |
| Length | 105mm |
| Depth | 130mm |
| Height | 68mm |
| Dimensions | 105 x 130 x 68mm |
| Leakage Current | 7.9 mA |
| Resistance | 5mΩ |
| Standards Met | UL 1283 |
