Snap Action Limit Switch Plunger Die Cast Zinc, NO/NC, 480V [2LS1]; 808-6917
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Actuator Type | Plunger |
| Pole and Throw Configuration | DPDT |
| Normal State Configuration | NO/NC |
| Maximum Current | 0.416666666666667 |
| Housing Material | Die Cast Zinc |
| Maximum AC Voltage | 480V |
| Maximum DC Voltage | 550V |
| Connection Type | 1/2 in NPT Conduit |
| Contact Type | Snap Action |
| Terminal Type | Wire Lead |
| Length | 39.9mm |
| Width | 28.7mm |
| Maximum Operating Temperature | +71°C |
| Depth | 68.6mm |
| Dimensions | 39.9 x 28.7 x 68.6 mm |
| Mounting Orientation | Vertical |
| Minimum Operating Temperature | -29°C |
