Kudom 80 A Solid State Relay, Zero Crossing, Panel Mount, SCR, Triac, 280 V ac Maximum Load [KSI240A80-L]; 903-2999
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Maximum Load Current | 80 A |
| Mounting Type | Panel Mount |
| Minimum Load Voltage | 48 V ac |
| Maximum Load Voltage | 280 V ac |
| Minimum Control Voltage | 90 V ac |
| Maximum Control Voltage | 280 V ac |
| Switching Type | Zero Crossing |
| Terminal Type | Screw |
| Output Device | SCR, Triac |
| Maximum Turn On Time | 20 ms |
| Dimensions | 58.6 x 45.7 x 26.5mm |
| Depth | 45.7mm |
| Control Voltage Range | 90 → 280 V ac |
| Load Voltage Range | 48 → 280V ac |
| Operating Temperature Range | -30 → +80°C |
| Off State Leakage Current | 5 mA |
| Special Features | Internal MOV, Internal RC, LED Indication, Superior Thermal Performance, TVS Protection Circuit as Option |
| Standards Met | CE, TUV, UL |
| Relay Type | Industrial Single Phase Relay |
| Height | 26.5mm |
| Length | 58.6mm |
