Kudom 60 A Solid State Relay 3 Phase, Zero Crossing, Panel Mount, SCR, 530 V ac Maximum Load [KSQF480D60]; 903-2914
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Maximum Load Current | 60 A |
| Mounting Type | Panel Mount |
| Minimum Load Voltage | 48 V ac |
| Maximum Load Voltage | 530 V ac |
| Minimum Control Voltage | 4 V dc |
| Maximum Control Voltage | 32 V dc |
| Switching Type | Zero Crossing |
| Terminal Type | Screw |
| Output Device | SCR |
| Maximum Turn On Time | 1 (1/2 AC Cycle) ms |
| Dimensions | 105 x 78 x 38mm |
| Standards Met | CE, RoHS Compliant |
| Special Features | Dielectric Strength≥4000 Vrms, Internal MOV, RC Protection Circuit |
| Operating Temperature Range | -30 → +80°C |
| Length | 105mm |
| Off State Leakage Current | 5 mA |
| Height | 38mm |
| Control Voltage Range | 4 → 32 V dc |
| Depth | 78mm |
| Load Voltage Range | 48 → 530V ac |
