Kudom 80 A Solid State Relay, Zero Cross, Panel Mount, SCR, 530 V ac Maximum Load [KSQF480D80]; 102-5556
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Maximum Load Current | 80 A |
| Mounting Type | Panel Mount |
| Minimum Load Voltage | 48 V ac |
| Maximum Load Voltage | 530 V ac |
| Minimum Control Voltage | 4 V dc |
| Maximum Control Voltage | 32 V dc |
| Switching Type | Zero Cross |
| Terminal Type | Screw |
| Output Device | SCR |
| Maximum Turn On Time | 1 (+1/2 cycle) ms |
| Dimensions | 105 x 78 x 38mm |
| Special Features | Internal MOV/RC Protection Circuit, Opto-Isolation |
| Operating Temperature Range | -30 → +80°C |
| Length | 105mm |
| Standards Met | CE |
| Off State Leakage Current | 5 mA |
| Relay Type | Three Phase |
| Load Voltage Range | 48 → 530V ac |
| Control Voltage Range | 4 → 32 V dc |
| Depth | 78mm |
| Height | 38mm |
