IPB014N06NATMA1 N-Channel MOSFET, 180 A, 60 V OptiMOS 5, 7-Pin D2PAK Infineon [IPB014N06NATMA1]; 178-5076
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Channel Type | N |
| Maximum Continuous Drain Current | 180 A |
| Maximum Drain Source Voltage | 60 V |
| Package Type | D2PAK (TO-263) |
| Mounting Type | Surface Mount |
| Pin Count | 7 |
| Maximum Drain Source Resistance | 2.1 mΩ |
| Channel Mode | Enhancement |
| Maximum Power Dissipation | 214 W |
| Transistor Configuration | Single |
| Maximum Gate Source Voltage | -20 V, +20 V |
| Number of Elements per Chip | 1 |
| Width | 11.05mm |
| Typical Gate Charge @ Vgs | 106 nC @ 10 V |
| Height | 4.57mm |
| Series | OptiMOS 5 |
| Maximum Operating Temperature | +175 °C |
| Length | 10.31mm |
| Forward Diode Voltage | 1.2V |
| Transistor Material | Si |
| Minimum Operating Temperature | -55 °C |
