IXYS, MCMA260P1600YA, Dual Thyristor Module SCR, 260A 1600V, 7-Pin Case Y4 [MCMA260P1600YA]; 801-1550
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Thyristor Type | SCR Module |
| Maximum Gate Trigger Voltage | 3V |
| Maximum Gate Trigger Current | 220mA |
| Maximum Holding Current | 150mA |
| Rated Average On-State Current | 260A |
| Repetitive Peak Reverse Voltage | 1600V |
| Surge Current Rating | 8.97kA |
| Mounting Type | Panel Mount |
| Package Type | Case Y4 |
| Pin Count | 7 |
| Peak On-State Voltage | 1.33V |
| Repetitive Peak Forward Blocking Voltage | 1600V |
| Dimensions | 94 x 34 x 30mm |
| Width | 34mm |
| Height | 30mm |
| Length | 94mm |
| Maximum Operating Temperature | +125 °C |
| Minimum Operating Temperature | -40 °C |
