IXYS, MCO500-12IO1, Thyristor Module SCR, 560A 1200V, 4-Pin Y1 CU [MCO500-12IO1]; 168-4517
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Thyristor Type | SCR Module |
| Maximum Gate Trigger Voltage | 2V |
| Maximum Gate Trigger Current | 300mA |
| Maximum Holding Current | 300mA |
| Rated Average On-State Current | 560A |
| Repetitive Peak Reverse Voltage | 1200V |
| Surge Current Rating | 17kA |
| Mounting Type | Panel Mount |
| Package Type | Y1 CU |
| Pin Count | 4 |
| Peak On-State Voltage | 1.3V |
| Repetitive Peak Forward Blocking Voltage | 1200V |
| Repetitive Peak Off-State Current | 40mA |
| Dimensions | 92 x 50 x 49mm |
| Maximum Operating Temperature | +140 °C |
| Width | 50mm |
| Length | 92mm |
| Minimum Operating Temperature | -40 °C |
| Height | 49mm |
