KEMET 680μF 400V dc Aluminium Capacitor, Through Hole 35 Dia. x 45mm +85°C 35mm 10mm [ALA7DA681DE400]; 176-2522
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 680 µF |
| Voltage | 400 V dc |
| Mounting Type | Through Hole |
| Technology | Electrolytic |
| Dimensions | 35 Dia. x 45mm |
| Height | 45mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 35mm |
| Maximum Operating Temperature | +85°C |
| Lead Pitch | 10mm |
| Series | ALA7D |
| Tolerance | ±20% |
| Automotive Standard | AEC-Q200 |
| Leakage Current | 1.632 mA |
| Polarised | Polar |
| Equivalent Series Resistance | 263.4 (100 Hz) mΩ, 1628 (10 kHz) mΩ |
| Ripple Current | 2.84 (100 Hz) A, 5.82 (10 kHz) A |
