KEMET 300μF 500V dc Aluminium Capacitor, Through Hole 30 Dia. x 50mm +105°C 30mm 10mm [ALA8DA301CF500]; 176-2519
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 300 µF |
| Voltage | 500 V dc |
| Mounting Type | Through Hole |
| Technology | Electrolytic |
| Dimensions | 30 Dia. x 50mm |
| Height | 50mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 30mm |
| Maximum Operating Temperature | +105°C |
| Lead Pitch | 10mm |
| Series | ALA8D |
| Equivalent Series Resistance | 506.4 (10 kHz) mΩ, 687.4 (100 Hz) mΩ |
| Ripple Current | 1.99 (100 Hz) A, 4.77 (10 kHz) A |
| Tolerance | ±20% |
| Leakage Current | 900 μA |
| Polarised | Polar |
| Automotive Standard | AEC-Q200 |
