KEMET 180μF 550V dc Aluminium Electrolytic Capacitor 30 x 50mm +85°C 30mm 10mm 50mm [ALC10A181CF550]; 173-1960
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 180 µF |
| Voltage | 550 V dc |
| Mounting Type | Snap-In |
| Technology | Electrolytic |
| Dimensions | 30 x 50mm |
| Height | 50mm |
| Length | 50mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 30mm |
| Maximum Operating Temperature | +85°C |
| Lifetime | 13000 h @ +85 °C/550V dc/Ir, 21000 h @ +85 °C/550V dc |
| Lead Pitch | 10mm |
| Series | ALC10 |
| Tolerance | ±20% |
| Polarised | Polar |
| Equivalent Series Resistance | 1.914Ω |
| Ripple Current | 1.52 A @ 100 Hz, 2.47 A @ 10 kHz |
| Leakage Current | 0.594 mA |
