KEMET 470μF 550V dc Aluminium Electrolytic Capacitor 35 x 80mm +85°C 35mm 10mm 80mm [ALC10A471DL550]; 173-2004
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 470 µF |
| Voltage | 550 V dc |
| Mounting Type | Snap-In |
| Technology | Electrolytic |
| Dimensions | 35 x 80mm |
| Height | 80mm |
| Length | 80mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 35mm |
| Maximum Operating Temperature | +85°C |
| Lead Pitch | 10mm |
| Lifetime | 15000 h @ +85 °C/550V dc/Ir, 24000 h @ +85 °C/550V dc |
| Series | ALC10 |
| Tolerance | ±20% |
| Leakage Current | 1.551 mA |
| Polarised | Polar |
| Ripple Current | 2.87 A @ 100 Hz, 4.43 A @ 10 kHz |
| Equivalent Series Resistance | 746mΩ |
