KEMET 56μF 550V dc Aluminium Electrolytic Capacitor 25 x 30mm +85°C 25mm 10mm 30mm [ALC10A560BB550]; 173-5080
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 56 µF |
| Voltage | 550 V dc |
| Mounting Type | Snap-In |
| Technology | Electrolytic |
| Dimensions | 25 x 30mm |
| Height | 30mm |
| Length | 30mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 25mm |
| Maximum Operating Temperature | +85°C |
| Lifetime | 10000 h @ +85 °C/550V dc/Ir, 16000 h @ +85 °C/550V dc |
| Lead Pitch | 10mm |
| Series | ALC10 |
| Equivalent Series Resistance | 6.118Ω |
| Ripple Current | 1.13 A @ 10 kHz, 680 mA @ 100 Hz |
| Polarised | Polar |
| Leakage Current | 0.1848 mA |
| Tolerance | ±20% |
