KEMET 680μF 550V dc Aluminium Electrolytic Capacitor 40 x 80mm +85°C 40mm 10mm 80mm [ALC10A681EL550]; 172-6920
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 680 µF |
| Voltage | 550 V dc |
| Mounting Type | Snap-In |
| Technology | Electrolytic |
| Dimensions | 40 x 80mm |
| Height | 80mm |
| Length | 80mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 40mm |
| Maximum Operating Temperature | +85°C |
| Lifetime | 18000 h @ +85 °C/550V dc/Ir, 29000 h @ +85 °C/550V dc |
| Lead Pitch | 10mm |
| Series | ALC10 |
| Tolerance | ±20% |
| Polarised | Polar |
| Equivalent Series Resistance | 514mΩ |
| Ripple Current | 3.87 A @ 100 Hz, 6.18 A @ 10 kHz |
| Leakage Current | 2.244 mA |
