KEMET 1200μF 550V dc Aluminium Electrolytic Capacitor 45 x 105mm +85°C 45mm 25mm 105mm [ALC10G122FP550]; 173-5170
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 1200 µF |
| Voltage | 550 V dc |
| Mounting Type | Snap-In |
| Technology | Electrolytic |
| Dimensions | 45 x 105mm |
| Height | 105mm |
| Length | 105mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 45mm |
| Maximum Operating Temperature | +85°C |
| Lead Pitch | 25mm |
| Lifetime | 18000 h @ +85 °C/550V dc/Ir, 29000 h @ +85 °C/550V dc |
| Series | ALC10 |
| Ripple Current | 5.6 A @ 100 Hz, 8.59 A @ 10 kHz |
| Equivalent Series Resistance | 296mΩ |
| Tolerance | ±20% |
| Polarised | Polar |
| Leakage Current | 3.96 mA |
