KEMET 15000μF 250V dc Aluminium Electrolytic Capacitor, Chassis Mount 77 (Dia.) x 220mm +85°C 77mm 31.8mm [ALS30A153NT250]; 172-6959
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 15000 µF |
| Voltage | 250 V dc |
| Mounting Type | Screw Mount |
| Technology | Electrolytic |
| Dimensions | 77 (Dia.) x 220mm |
| Height | 220mm |
| Depth | 220mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 77mm |
| Maximum Operating Temperature | +85°C |
| Lifetime | 20000 (Rated Voltage & Ripple Current at 85C) h, 40000 (Rated Voltage at 85C) h |
| Lead Pitch | 31.8mm |
| Series | ALS30 |
| Ripple Current | 32.4 (100Hz 85C) A, 36.5 (10kHz 85C) A |
| Tolerance | ±20% |
| Leakage Current | 6 mA |
| Polarised | Polar |
| Equivalent Series Resistance | 10 (10 kHz 20C) mΩ, 12 (100 Hz 20C) mΩ |
