KEMET 1000μF 500V dc Aluminium Electrolytic Capacitor, Stud Mount 66 (Dia.) x 105mm +85°C 66mm 28.5mm [ALS31A102MF500]; 125-1087
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 1000 µF |
| Voltage | 500 V dc |
| Mounting Type | Screw Mount |
| Technology | Electrolytic |
| Dimensions | 66 (Dia.) x 105mm |
| Height | 105mm |
| Depth | 105mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 66mm |
| Maximum Operating Temperature | +85°C |
| Lead Pitch | 28.5mm |
| Lifetime | 19000 (Rated Voltage & Ripple Current at 85C) h, 38000 (Rated Voltage at 85C) h |
| Series | ALS31 |
| Tolerance | ±20% |
| Leakage Current | 3 mA |
| Polarised | Polar |
| Ripple Current | 8.1 (100Hz 85C) A, 13.8 (10kHz 85C) A |
| Equivalent Series Resistance | 96 (10 kHz 20C) mΩ, 175 (100 Hz 20C) mΩ |
