KEMET 10000μF 250V dc Aluminium Electrolytic Capacitor, Stud Mount 77 (Dia.) x 146mm +85°C 77mm 31.8mm [ALS31A103NP250]; 173-5183
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 10000 µF |
| Voltage | 250 V dc |
| Mounting Type | Screw Mount |
| Technology | Electrolytic |
| Dimensions | 77 (Dia.) x 146mm |
| Height | 146mm |
| Depth | 146mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 77mm |
| Maximum Operating Temperature | +85°C |
| Lead Pitch | 31.8mm |
| Lifetime | 20000 (Rated Voltage & Ripple Current at 85C) h, 40000 (Rated Voltage at 85C) h |
| Series | ALS31 |
| Tolerance | ±20% |
| Equivalent Series Resistance | 16 (10 kHz 20C) mΩ, 19 (100 Hz 20C) mΩ |
| Ripple Current | 21.6 (100Hz 85C) A, 24 (10kHz 85C) A |
| Polarised | Polar |
| Leakage Current | 6 mA |
