KEMET 2200μF 550V dc Aluminium Electrolytic Capacitor, Stud Mount 66 x 146mm +85°C 66mm 28.5mm 146mm [ALS61A222MP550]; 173-5178
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 2200 µF |
| Voltage | 550 V dc |
| Mounting Type | Screw Mount |
| Technology | Electrolytic |
| Dimensions | 66 x 146mm |
| Height | 146mm |
| Length | 146mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 66mm |
| Maximum Operating Temperature | +85°C |
| Lifetime | 19000 h @ +85 °C/550V dc/Ir, 38000 h @ +85 °C/550V dc |
| Lead Pitch | 28.5mm |
| Series | ALS60 |
| Leakage Current | 6 mA |
| Tolerance | ±20% |
| Ripple Current | 11.3 A @100 Hz, 17.1 A @10 kHz |
| Equivalent Series Resistance | 140mΩ |
| Polarised | Polar |
