| Manufacturer |
LAPP |
| Manufacturer Part No. |
0027576 |
| Type of wire |
control cable |
| Cable structure |
3G1.5mm2 |
| Wire insulation material |
PUR |
| Insulation colour |
grey |
| Core structure |
stranded |
| Kind of core |
Cu |
| Manufacturer series |
ÖLFLEX® FD 855 P |
| Core section |
1.5mm2 |
| Number of cores |
3 |
| Cable external diameter |
7.3mm |
| Rated voltage |
0.3kV/0.5kV |
| Core marking |
black, numbered + ground wire |
| Shield structure |
unshielded |
| CPR standard |
Eca |
| Flexibility class |
6 |
| Earth core |
yellow-green |
| Resistance to |
mechanical stesses, most of oils, ozone, temperature, to weather conditions, UV rays |
| Cable application |
power chain |
| Kind of material |
halogen free, no flame propagation |
| Conform to the norm |
CSA AWM I/II A/B FT1 CSA FT2 EN 50618 EN 50620 IEC 60332-1-2 IEC 61892-4 UL 758 UL 10263 UL 21576 VW-1 |
| Information |
The UL Label and Mark on full factory packaging only |
| Operating temperature |
-50...80°C |
| Gross weight |
75.075 g |
| EAN code |
4044773014433 |
