Littelfuse 1.1A Resettable Surface Mount Fuse, 24V dc [1812L110/24DR]; 174-0331
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Trip Current | 1.95A |
| Voltage Rating | 24 V dc |
| Time to Trip | 0.5s |
| Hold Current | 1.1 A |
| Maximum Current | 20 A |
| Length | 4.73mm |
| Height | 1.25mm |
| Width | 3.41mm |
| Terminal Material | Solder Plated Copper |
| Minimum Resistance | 0.06Ω |
| Maximum Resistance | 200mΩ |
| Power Dissipation | 0.8W |
| Minimum Operating Temperature | -40°C |
| Package Size | 4532 |
| Maximum Operating Temperature | +85°C |
| Operating Temperature Range | -40 → +85 °C |
| Dimensions | 4.73 x 3.41 x 1.25mm |
| Fuse Speed | F |
| Series | 1812L |
