| Manufacturer |
METRIX |
| Manufacturer Part No. |
MX0350Z |
| Type of meter |
multifunction |
| Kind of meter |
AC pincers type, digital |
| Kind of display used |
LCD |
| Display parameters |
(6000) |
| Max. diameter of measured cable |
26mm |
| AC current measuring range |
50mA...400A |
| AC current measuring accuracy |
±(1.9% + 5 digit) |
| DC voltage measuring range |
200mV...600V |
| DC voltage measuring accuracy |
±(1% + 2 digit) |
| AC voltage measuring range |
500mV...600V |
| AC voltage measuring accuracy |
±(1.5% + 5 digit) |
| True effective value measurement |
True RMS |
| Resistance measuring range |
200mΩ...399.9Ω |
| Frequency measuring range |
2...1MHz |
| Frequency measuring accuracy |
±(0.1%+1 digit) |
| Dimensions |
199x75x36mm |
| Measurement |
AC current, AC voltage, continuity, DC voltage, frequency, resistance |
| Conform to the norm |
CAT III 600V EN 61010 |
| Bargraph |
yes |
| Resistance measuring accuracy |
±(1%+2 digit) |
| Measuring instrument features |
automatic power-off, autoranging, HOLD function |
| Power supply |
battery LR03 AAA 1,5V x2 |
| Standard equipment |
case, test leads |
| Battery/ rechargeable battery |
battery LR03 AAA 1,5V x2 |
| Gross weight |
1000 g |
