Microchip Technology ATMEGA1280V-8CU, 8bit AVR Microcontroller, 8MHz, 128 kB Flash, 100-Pin CBGA [ATMEGA1280V-8CU]; 127-8225
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Family Name | ATmega |
| Package Type | CBGA |
| Mounting Type | Surface Mount |
| Pin Count | 100 |
| Device Core | AVR |
| Data Bus Width | 8bit |
| Program Memory Size | 128 kB |
| Maximum Frequency | 8MHz |
| RAM Size | 8 kB |
| Number of PWM Units | 2 |
| ADC Channels | 16 |
| Typical Operating Supply Voltage | 1.8 → 5.5 V |
| Program Memory Type | Flash |
| Number of Timers | 2 |
| Timers | 1(2 x 8 bit), 1(4 x 16 bit) |
| Dimensions | 9.1 x 9.1 x 0.8mm |
| Maximum Operating Temperature | +85 °C |
| Timer Resolution | 8 bit, 16 bit |
| Pulse Width Modulation | 1(12 x 16 bit), 1(4 x 8 bit) |
| ADC Resolution | 10bit |
| ADCs | 1(16 x 10 bit) |
| Minimum Operating Temperature | -40 °C |
| PWM Resolution | 8 bit, 16 bit |
| Instruction Set Architecture | RISC |
| Length | 9.1mm |
| Number of ADC Units | 1 |
| PWM Channels | 16 |
| Width | 9.1mm |
| Height | 0.8mm |
