Microchip Technology ATTINY861A-MU, 8bit AVR Microcontroller, 20MHz, 8 kB Flash, 32-Pin MLF [ATTINY861A-MU]; 133-1681
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Family Name | AVR |
| Package Type | MLF |
| Mounting Type | Surface Mount |
| Pin Count | 32 |
| Device Core | AVR |
| Data Bus Width | 8bit |
| Program Memory Size | 8 kB |
| Maximum Frequency | 20MHz |
| RAM Size | 512 B |
| Number of PWM Units | 1 |
| ADC Channels | 11 |
| Typical Operating Supply Voltage | 1.8 → 5.5 V |
| Number of Timers | 2 |
| ADCs | 1(11 x 10 bit) |
| Length | 5.1mm |
| Maximum Operating Temperature | +85 °C |
| Program Memory Type | Flash |
| Number of ADC Units | 1 |
| Instruction Set Architecture | RISC |
| Pulse Width Modulation | 1(6 Channel) |
| Dimensions | 5.1 x 5.1 x 0.95mm |
| Minimum Operating Temperature | -40 °C |
| Timers | 1 x 8/10 bit, 1 x 8/16 bit |
| Timer Resolution | 8 bit, 10 bit, 16 bit |
| Height | 0.95mm |
| PWM Channels | 6 |
| Width | 5.1mm |
| ADC Resolution | 10bit |
