Microchip Technology MIC4420ZT Low Side MOSFET Power Driver, 6 (Typ.)A 5-Pin, TO-220 [MIC4420ZT]; 177-0943
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Number of Drivers | 1 |
| Minimum Operating Supply Voltage | 4.5 V |
| Maximum Operating Supply Voltage | 18 V |
| Topology | Low Side |
| Mounting Type | Through Hole |
| Peak Output Current | 6 (Typ.)A |
| Number of Outputs | 1 |
| Polarity | Non-Inverting |
| Package Type | TO-220 |
| Pin Count | 5 |
| Input Logic Compatibility | CMOS, TTL |
| Height | 14.68mm |
| Length | 10.16mm |
| Dimensions | 10.16 x 4.5 x 14.68mm |
| Time Delay | 100ns |
| Width | 4.5mm |
| Fall Time | 60ns |
| Minimum Operating Temperature | 0 °C |
| Maximum Operating Temperature | +70 °C |
| Rise Time | 60ns |
