Microchip Technology PIC16F15325-I/JQ, 8bit 8 bit CPU Microcontroller, 32MHz, 14 kB Flash, 16-Pin UQFN [PIC16F15325-I/JQ]; 177-2673
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Family Name | PIC16F |
| Package Type | UQFN |
| Mounting Type | Surface Mount |
| Pin Count | 16 |
| Device Core | 8 bit CPU |
| Data Bus Width | 8bit |
| Program Memory Size | 14 kB |
| Maximum Frequency | 32MHz |
| RAM Size | 1 kB |
| Number of PWM Units | 1 |
| ADC Channels | 11 |
| Number of SPI Channels | 1 |
| Typical Operating Supply Voltage | 5.5 (Maximum) V |
| Number of UART Channels | 2 |
| Length | 4mm |
| ADCs | 1 (11 x 10 bit) |
| Number of Timers | 2 |
| Number of I2C Channels | 1 |
| Timers | 1 (1 x 8 bit), 1 (2 x 16 bit) |
| Minimum Operating Temperature | -40 °C |
| Dimensions | 4 x 4 x 0.5mm |
| PWM Resolution | 10bit |
| Pulse Width Modulation | 1 (4 x 10 bit) |
| Number of ADC Units | 1 |
| Program Memory Type | Flash |
| Maximum Operating Temperature | +85 °C |
| Width | 4mm |
| PWM Channels | 4 |
| Height | 0.5mm |
| Timer Resolution | 8 bit, 16 bit |
| ADC Resolution | 10bit |
| Number of USART Channels | 2 |
