MICROCHIP TECHNOLOGY IC: PIC microcontroller; 1.5kB; 8MHz; ADC,ICSP; SMD; SOIC8; PIC12 [PIC12F510T-I/SN]
The Microchip PIC12F510T is a 8pin 8 bit flash microcontroller. The PIC12F510T has 6 I/O pins from which 5 I/O pins with individual direction control and 1 input only pin. This file has limited permissions. 8 pin packaging Precision 4 to 8 MHz internal oscillator 3 channels 8 bit ADC On board Comparator 1.125ms DRT Device Reset Timer Baseline Core with 33 Instructions 2 Stack Levels All single cycle Instructions except for program branches which are two cycles 12 bit wide instructions 8 bit wide data path 25 mA source and sink current I/O Low power 100nA sleep current One 8 bit timer TMR0 Watchdog timer In Circuit Serial Programming capability In Circuit debugging support Programmable code protection
The Microchip PIC12F510T is a 8pin 8 bit flash microcontroller. The PIC12F510T has 6 I/O pins from which 5 I/O pins with individual direction control and 1 input only pin.
This file has limited permissions.
8 pin packaging
Precision 4 to 8 MHz internal oscillator
3 channels 8 bit ADC
On board Comparator
1.125ms DRT Device Reset Timer
Baseline Core with 33 Instructions 2 Stack Levels
All single cycle Instructions except for program branches which are two cycles
12 bit wide instructions
8 bit wide data path
25 mA source and sink current I/O
Low power 100nA sleep current
One 8 bit timer TMR0
Watchdog timer
In Circuit Serial Programming capability
In Circuit debugging support
Programmable code protection
