NJM2403M New Japan Radio, Dual Comparator, Open Collector O/P, 1.5μs 3 → 28 V 8-Pin DMP [NJM2403M]; 178-2403
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Comparator Type | General Purpose |
| Mounting Type | Surface Mount |
| Package Type | DMP |
| Power Supply Type | Dual, Single |
| Output Type | Open Collector |
| Number of Channels per Chip | 2 |
| Typical Response Time | 1.5µs |
| Pin Count | 8 |
| Typical Single Supply Voltage | 3 → 28 V |
| Dimensions | 5 x 5 x 1.6mm |
| Length | 5mm |
| Width | 5mm |
| Height | 1.6mm |
| Maximum Operating Temperature | +85 °C |
| Typical Voltage Gain | 106 dB |
| Typical Dual Supply Voltage | ±12 V, ±15 V, ±3 V, ±5 V, ±9 V |
| Minimum Operating Temperature | -40 °C |
