NEWHAVEN DISPLAY INTERNATIONAL NHD-3.5-320240MF-ATXL#-T-1 TFT LCD Colour Display / Touch Screen, 1.8in, 128 x 160pixels [NHD-3.5-320240MF-ATXL#-T-1]; 909-2039
Mã kho: 9092039
Mã nhà sản xuất: NHD-3.5-320240MF-ATXL#-T-1
Tên nhà sản xuất:
NEWHAVEN DISPLAY INTERNATIONAL
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Diagonal Display Size | 3.5in |
| Interface Type | Parallel, RGB |
| Resolution | 128 x 160pixels |
| Touch Screen | Yes |
| Viewing Area Dimensions | 52.56 x 70.08mm |
| Touch Screen Type | Resistive |
| Supply Voltage | 3.5 V |
| Backlight Type | LED |
| AC or DC Input Voltage | Dc |
| Dimensions | 46.75 x 34.7 x 2.25mm |
| Display Matrix Technology | TFT |
| Minimum Operating Temperature | -40°C |
| Maximum Operating Temperature | 85°C |
| Depth | 2.25mm |
| Height | 46.75mm |
| Contrast Ratio | 14.5840277777778 |
| Operating Temperature Range | -20 → +70°C |
| Number of Colours | 262144 |
| Voltage Rating | 3.3V |
| Width | 34.7mm |
| Viewing Area Height | 52.56mm |
| Current Rating | 40mA |
| Standards Met | RoHS Compliant |
| Response Time | 40ms |
| Viewing Area Width | 70.08mm |
| Brightness | 100cd/m² |
