PSMN1R5-30YLC,115 N-Channel MOSFET, 100 A, 30 V, 4-Pin LFPAK Nexperia [PSMN1R5-30YLC,115]; 816-6969
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Channel Type | N |
| Maximum Continuous Drain Current | 100 A |
| Maximum Drain Source Voltage | 30 V |
| Package Type | LFPAK |
| Mounting Type | Surface Mount |
| Pin Count | 4 |
| Maximum Drain Source Resistance | 2 mΩ |
| Channel Mode | Enhancement |
| Maximum Gate Threshold Voltage | 1.95V |
| Minimum Gate Threshold Voltage | 1.05V |
| Maximum Power Dissipation | 179 W |
| Transistor Configuration | Single |
| Maximum Gate Source Voltage | -20 V, +20 V |
| Number of Elements per Chip | 1 |
| Typical Gate Charge @ Vgs | 65 nC @ 10 V |
| Width | 4.1mm |
| Height | 1.05mm |
| Maximum Operating Temperature | +175 °C |
| Transistor Material | Si |
| Minimum Operating Temperature | -55 °C |
| Length | 5mm |
