Nichicon 47μF 16V dc Aluminium Polymer Capacitor, Surface Mount 5 (Dia.) x 6mm +105°C 5mm [PCG1C470MCL1GS]; 541-425
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 47 µF |
| Voltage | 16 V dc |
| Mounting Type | Surface Mount |
| Technology | Polymer |
| Dimensions | 5 (Dia.) x 6mm |
| Height | 6mm |
| Minimum Operating Temperature | -55°C |
| Diameter | 5mm |
| Maximum Operating Temperature | +105°C |
| Lifetime | 2000h |
| Series | CG |
| Equivalent Series Resistance | 40mΩ |
| Ripple Current | 1.5A |
| Leakage Current | 150 μA |
| Polarised | Polar |
| Tolerance | ±20% |
