Nichicon 5.6μF 50V dc Aluminium Polymer Capacitor, Surface Mount 6.3 (Dia.) x 5.9mm +125°C 6.3mm 2.1mm [PCX1H5R6MCL1GS]; 173-3291
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 5.6 µF |
| Voltage | 50 V dc |
| Mounting Type | Surface Mount |
| Technology | Polymer |
| Dimensions | 6.3 (Dia.) x 5.9mm |
| Height | 5.9mm |
| Minimum Operating Temperature | -55°C |
| Diameter | 6.3mm |
| Maximum Operating Temperature | +125°C |
| Lifetime | 3000h |
| Lead Pitch | 2.1mm |
| Series | CX |
| Equivalent Series Resistance | 105mΩ |
| Tolerance | ±20% |
| Polarised | Polar |
| Ripple Current | 700mArms |
| Leakage Current | 56 μA |
