Nichicon 100μF 10V dc Aluminium Electrolytic Capacitor, Surface Mount 6.3 (Dia.) x 7.7mm +105°C 6.3mm [UUA1A101MCL1GS]; 490-7804
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 100 µF |
| Voltage | 10 V dc |
| Mounting Type | Surface Mount |
| Technology | Electrolytic |
| Dimensions | 6.3 (Dia.) x 7.7mm |
| Height | 7.7mm |
| Minimum Operating Temperature | -55°C |
| Diameter | 6.3mm |
| Maximum Operating Temperature | +105°C |
| Lifetime | 3000h |
| Series | UA |
| Polarised | Polar |
| Tolerance | ±20% |
| Leakage Current | 3 μA |
| Ripple Current | 81mA |
