Nichicon 220μF 10V dc Aluminium Electrolytic Capacitor, Surface Mount 8 (Dia.) x 6.2mm +85°C 8mm 2.3mm [UUR1A221MCL1GS]; 171-0704
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 220 µF |
| Voltage | 10 V dc |
| Mounting Type | Surface Mount |
| Technology | Electrolytic |
| Dimensions | 8 (Dia.) x 6.2mm |
| Height | 6.2mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 8mm |
| Maximum Operating Temperature | +85°C |
| Lead Pitch | 2.3mm |
| Lifetime | 2000h |
| Series | UR |
| Leakage Current | 66 μA |
| Polarised | Polar |
| Tolerance | ±20% |
| Ripple Current | 175mA |
