Nichicon 10μF 35V dc Aluminium Electrolytic Capacitor, Surface Mount 5 (Dia.) x 5.4mm +105°C 5mm 1.3mm [UWT1V100MCL1GB]; 167-7876
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 10 µF |
| Voltage | 35 V dc |
| Mounting Type | Surface Mount |
| Technology | Electrolytic |
| Dimensions | 5 (Dia.) x 5.4mm |
| Height | 5.4mm |
| Minimum Operating Temperature | -55°C |
| Diameter | 5mm |
| Maximum Operating Temperature | +105°C |
| Lifetime | 1000h |
| Lead Pitch | 1.3mm |
| Series | WT |
| Tolerance | ±20% |
| Polarised | Polar |
| Ripple Current | 25mA |
| Leakage Current | 3.5 μA |
