Nichicon 4.7μF 25V dc Aluminium Electrolytic Capacitor, Surface Mount 3 (Dia.) x 5.5mm +85°C 3mm 0.8mm [UWX1E4R7MCL2GB]; 739-5566
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 4.7 µF |
| Voltage | 25 V dc |
| Mounting Type | Surface Mount |
| Technology | Electrolytic |
| Dimensions | 3 (Dia.) x 5.5mm |
| Height | 5.5mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 3mm |
| Maximum Operating Temperature | +85°C |
| Lead Pitch | 0.8mm |
| Lifetime | 2000h |
| Series | WX |
| Leakage Current | 3 μA |
| Ripple Current | 12mA |
| Polarised | Polar |
| Tolerance | ±20% |
