NXP LPC1778FBD208,551, 32bit ARM Cortex M3 Microcontroller, 120MHz, 512 kB Flash, 208-Pin LQFP [LPC1778FBD208,551]; 103-8084
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Family Name | LPC178x/7x |
| Package Type | LQFP |
| Mounting Type | Surface Mount |
| Pin Count | 208 |
| Device Core | ARM Cortex M3 |
| Data Bus Width | 32bit |
| Program Memory Size | 512 kB |
| Maximum Frequency | 120MHz |
| RAM Size | 4 kB, 96 kB |
| USB Channels | 1 x Device, 1 x Host, 1 x OTG |
| Number of PWM Units | 1 |
| ADC Channels | 8 |
| Number of SPI Channels | 3 |
| Typical Operating Supply Voltage | 3.3 V |
| Maximum Operating Temperature | +85 °C |
| Length | 28.1mm |
| ADCs | 8 x 12 bit |
| Timer Resolution | 32bit |
| Height | 1.45mm |
| PWM Channels | 6 |
| Number of ADC Units | 1 |
| Number of CAN Channels | 2 |
| Instruction Set Architecture | RISC |
| Number of I2C Channels | 3 |
| Number of Timers | 4 |
| Number of Ethernet Channels | 1 |
| Number of UART Channels | 5 |
| Program Memory Type | Flash |
| Pulse Width Modulation | 1(6 Channel) |
| Dimensions | 28.1 x 28.1 x 1.45mm |
| Timers | 4 x 32 bit |
| Width | 28.1mm |
| ADC Resolution | 12bit |
| Minimum Operating Temperature | -40 °C |
