SPDT PCB Mount Latching Relay 2 A, 5V dc For Use In Signal Applications [G6EU134PSTUS5DC]; 789-7583
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Coil Voltage | 5 V dc |
| Contact Configuration | SPDT |
| Mounting Type | PCB Mount |
| Switching Current | 0.0833333333333333 |
| Maximum Switching Voltage AC | 250V ac |
| Maximum Switching Voltage DC | 220V dc |
| Maximum Switching Power DC | 60 W |
| Length | 16mm |
| Depth | 10mm |
| Height | 8mm |
| Dimensions | 16 x 10 x 8mm |
| Terminal Type | Through Hole |
| Application | Signal |
| Operating Temperature Range | -40 → +70°C |
| Coil Resistance | 125 Ω |
| Maximum Switching Power AC | 50 VA |
| Life | 100 Million (Mechanical) operations, 500000 (Electrical) operations |
| Coil Power | 200mW |
| Isolation Coil To Contact | 1.5kV ac |
| Maximum Operating Temperature | +70°C |
| Contact Material | Gold Plated |
| Features | Bifurcated Crossbar Contact, High Sensitivity with Pick-up Coil Power, Sub-Miniature Type |
| Minimum Operating Temperature | -40°C |
| Electrical Life | 500000 operations |
