ON Semiconductor M74VHC1G135DTT1G, 2-Input NAND Schmitt Trigger Logic Gate, 5-Pin TSOP [M74VHC1G135DTT1G]; 145-3634
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Logic Function | NAND |
| Mounting Type | Surface Mount |
| Number of Elements | 1 |
| Number of Inputs per Gate | 2 |
| Schmitt Trigger Input | Yes |
| Package Type | TSOP |
| Pin Count | 5 |
| Logic Family | VHC |
| Input Type | Schmitt Trigger |
| Maximum Operating Supply Voltage | 5.5 V |
| Maximum Propagation Delay Time @ Maximum CL | 19.6 ns @ 50 pF |
| Minimum Operating Supply Voltage | 2 V |
| Maximum Low Level Output Current | 8mA |
| Width | 1.5mm |
| Dimensions | 3 x 1.5 x 1mm |
| Minimum Operating Temperature | -55 °C |
| Maximum Operating Temperature | +125 °C |
| Propagation Delay Test Condition | 50pF |
| Length | 3mm |
| Output Type | Open Drain |
| Height | 1mm |
