ON Semiconductor SMCJ48A, Uni-Directional TVS Diode, 2-Pin DO-214AB [SMCJ48A]; 903-4415
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Direction Type | Uni-Directional |
| Diode Configuration | Single |
| Maximum Clamping Voltage | 77.4V |
| Minimum Breakdown Voltage | 58.9V |
| Mounting Type | Surface Mount |
| Package Type | DO-214AB (SMC) |
| Maximum Reverse Stand-off Voltage | 48V |
| Pin Count | 2 |
| Maximum Peak Pulse Current | 19.4A |
| Number of Elements per Chip | 1 |
| Maximum Operating Temperature | +150 °C |
| Test Current | 1mA |
| Width | 6.25mm |
| Height | 2.45mm |
| Length | 8.15mm |
| Surge Current Rating | 200A |
| Dimensions | 8.15 x 6.25 x 2.45mm |
| Maximum Reverse Leakage Current | 5µA |
