Panasonic 680μF 2.5V dc Aluminium Polymer Capacitor, Through Hole 8 (Dia.) x 12mm +105°C 8mm 3.5mm [2R5SEP680M]; 166-6987
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 680 µF |
| Voltage | 2.5 V dc |
| Mounting Type | Through Hole |
| Technology | Polymer |
| Dimensions | 8 (Dia.) x 12mm |
| Height | 12mm |
| Minimum Operating Temperature | -55°C |
| Diameter | 8mm |
| Maximum Operating Temperature | +105°C |
| Lifetime | 2000h |
| Lead Pitch | 3.5mm |
| Series | OS-CON |
| Leakage Current | 340 μA |
| Tolerance | ±20% |
| Equivalent Series Resistance | 13mΩ |
| Ripple Current | 4.52A |
