SPDT PCB Mount Latching Relay 8 A, 24V dc For Use In Power Applications [DK1A1B-L2-24V]; 815-6570
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Coil Voltage | 24 V dc |
| Contact Configuration | SPDT |
| Switching Current | 0.333333333333333 |
| Mounting Type | PCB Mount |
| Maximum Switching Voltage AC | 250V |
| Maximum Switching Voltage DC | 125V |
| Maximum Switching Power DC | 240 W |
| Length | 20mm |
| Depth | 15mm |
| Height | 10mm |
| Dimensions | 20 x 15 x 10mm |
| Terminal Type | PCB Pin |
| Application | Power |
| Coil Power | 200mW |
| Life | 50000000 operations |
| Coil Resistance | 2.88 kΩ |
| Maximum Switching Power AC | 2 kVA |
| Features | Compact with High Capacity, High Breakdown Voltage, High Sensitivity |
| Contact Material | Silver Alloy |
| Minimum Operating Temperature | -40°C |
| Electrical Life | 100000 operations |
| Operating Temperature Range | -40 → +65°C |
| Maximum Operating Temperature | +65°C |
| Isolation Coil To Contact | 4kV rms |
