Panasonic 56μF 35V dc Hybrid Conductive Polymer Aluminium Capacitor, Surface Mount 6.3 (Dia.) x 5.8mm +125°C 6.3mm [EEHZK1V560P]; 131-1960
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 56 µF |
| Voltage | 35 V dc |
| Mounting Type | Surface Mount |
| Technology | Hybrid |
| Dimensions | 6.3 (Dia.) x 5.8mm |
| Depth | 5.8mm |
| Minimum Operating Temperature | -55°C |
| Diameter | 6.3mm |
| Maximum Operating Temperature | +125°C |
| Lead Pitch | 1.8mm |
| Lifetime | 4000h |
| Series | ZK |
| Leakage Current | ≤0.01 CV or 3 μA |
| Tolerance | ±20% |
| Polarised | Polar |
| Ripple Current | 1080mA |
| Dissipation Factor | 0.0012 |
| Equivalent Series Resistance | 60mΩ |
