IP67 Blue Button Tactile Switch, Single Pole Single Throw (SPST) 20 mA @ 15 V dc 0.3mm Surface Mount [EVQP6DB35]; 125-0181
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Contact Configuration | Single Pole Single Throw (SPST) |
| Terminal Type | J Bend |
| Switch Operation | Momentary |
| Actuator Length | 0.3mm |
| Actuator Colour | Blue |
| Actuator Type | Push Plate |
| Length | 4.1mm |
| Width | 4.1mm |
| Dimensions | 4.1 x 4.1mm |
| Mounting Type | Surface Mount |
| Contact Current Rating | 20 mA @ 15 V dc |
| IP Rating | IP67 |
| Operating Force | 1.6 N |
| Operating Temperature Range | -20 → +70°C |
| Minimum Operating Temperature | -20°C |
| Voltage Rating | 2 → 15V dc |
| Mechanical Life | 1000000Operations |
| Maximum Operating Temperature | +70°C |
