SPNO PCB Mount Latching Relay 8 A, 5V dc For Use In General Purpose Applications [ST1-L2-DC5V-F]; 811-3482
Original price
0₫
-
Original price
0₫
Original price
0₫
0₫
-
0₫
Current price
0₫
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Coil Voltage | 5 V dc |
| Contact Configuration | SPNO |
| Switching Current | 0.333333333333333 |
| Mounting Type | PCB Mount |
| Maximum Switching Voltage AC | 380V |
| Maximum Switching Voltage DC | 250V |
| Maximum Switching Power DC | 150 W |
| Length | 31mm |
| Depth | 14mm |
| Height | 11mm |
| Dimensions | 31 x 14 x 11mm |
| Terminal Type | PCB Pin |
| Application | General Purpose |
| Coil Resistance | 110 Ω |
| Operating Temperature Range | -40 → +60°C |
| Features | High Switching Capability |
| Minimum Operating Temperature | -40°C |
| Maximum Operating Temperature | +60°C |
| Isolation Coil To Contact | 3.75kV rms |
| Electrical Life | 100000 operations |
| Contact Material | Silver Alloy |
| Coil Power | 240mW |
| Life | 100000 (Electrical) operations, 10000000 (Mechanical) operations |
| Maximum Switching Power AC | 3.04 kVA |
