The 4-way adhesive backed cable tie mount in black is mounted with acrylic adhesive tape. It is 1" long x 1" wide (25.4 x 25.4 mm) and made of weather-resistant ABS plastic. It is used with miniature, intermediate, and standard cable ties. It is designed

Mã kho: PAJ804
Tên nhà sản xuất: Panduit
Original price 18.100₫ - Original price 18.100₫
Original price
18.100₫
18.100₫ - 18.100₫
Current price 18.100₫
📩 Liên hệ để có giá tốt: CV@chanhvinh.com

Wire Routing Management Protection / Cable Wire Ties Mounts Straps / Cable Tie Mounts: Panduit ABM2S-AT-C0

MÔ TẢ SẢN PHẨM

Panduit’s ABM2S-AT-C0 4-way acrylic-based adhesive backed cable tie mounts have been designed for fast installation and long-term performance and reliability. They are made of weather resistant ABS plastic. These mounts can be used with miniature, intermediate, and standard cable ties and are design

_THÔNG SỐ KỸ THUẬT:

Application Used with Miniature, Intermediate, and Standard Cables Ties
Product Type Cable Tie Mount
Color Black
Environment Indoor/Outdoor
Material Weather Resistant ABS
Maximum Compatible Panel Thickness (In.) 0.04
Maximum Compatible Panel Thickness (mm) 1
Maximum Operating Temperature (°C) 70
Maximum Operating Temperature (°F) 158
Minimum Operating Temperature (°C) -29
Minimum Operating Temperature (°F) -20
Mount Method Acrylic Adhesive Tape
Mounting Hole Thread Size 0.16
Overall Height (In.) 0.2
Overall Height (mm) 5.1
Overall Length (In.) 1
Overall Length (mm) 25.4
Overall Width (In.) 1
Overall Width (mm) 50.3
Resistance Properties UV Resistant
Standards Met CE Compliant, UL Recognized: E136577, RoHS Compliant
Static Load Capacity (kg) 0.227
Static Load Capacity (lb) 0.5
For Use With Miniature, Intermediate, Standard Cross-Section Ties
